Section 6: SEAKEEPER SPECIFICATIONS
SEAKEEPER 1 SPECIFICATIONS & SUMMARY
Rated RPM
9,750 RPM
Angular Momentum at Rated RPM
1,000 N-M-S
Anti-Rolling Torque at Rated RPM
2,620 N-M
Spool-up Time to Rated RPM (9750 RPM)
30 minutes (9,750 RPM)
Spool-up Time to Stabilization RPM
15 minutes (7,650 RPM)
Spool-up Power
DC Motor
600 Watts Max
Operating Power
DC (Sea state dependent) 300-600 Watts
Voltage
DC Input
12 VDC @ 55 Amps
Seawater Supply to Heat Exchanger
4 GPM (15 LPM) maximum
2 GPM (8 LPM) minimum
Ambient Air Temperature
32˚ - 140˚F (0 - 60 ˚C)
Weight
365 lbs (165kg)
Envelope Dimensions
22.9 L x 23.6 W x 15.7 H (inches)
0.582 L x 0.598 W x 0.398 H (meters)
Noise Output
At full operating RPM, steady state noise measured in the factory
at a 1-meter distance measures 62-64 dBC (sound levels may be
higher during spool-up).
