Section 2: ELECTRICAL INSTALLATION
2.1 Electrical Equipment Mounting
Precautions
 Each item of electrical equipment has specific mounting instructions. These instructions
should be followed to insure proper function of the Seakeeper 6.
1. TOUCH DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT
a. Console space required: Approx. 5.24 W x 3.70 H inches (133 x 94 mm)
b. Mounting Instructions, Surface Mount: See drawing 90438 for details
2. CAN COMMUNICATIONS TEE ADAPTER AND TERMINATOR MOUNTING
INSTRUCTIONS
a. Console space required, Rear: Approx. 4 W x 3 H inches (102 x 76 mm)
b. Mounting Instructions: Rear mount on vessel console panel, within 1 ft (0.3m) of
Display.
c. Hardware required: One mounting screw for .197” (5 mm) diameter mounting hole
on Tee Adapter.
3. USB EXTENSION CABLE ASSEMBLY MOUNTING INSTRUCTIONS
a. Console space required: Approx. 2 W x 2 H inches (51 x 51 mm), within 6 ft (2 m)
from Touch Display.
b. Mounting Instructions, Surface Mount: Use panel cutout as shown in section
2.5. Maximum panel thickness 1/8” (3.2 mm)
c. Install sealed USB connector end of the extender cable assembly in panel from
rear and secure with hex jam nut (provided) on front.
d. Connect M12 connector end of the extender cable assembly to the rear of the
Touch Display on receptacle AUX.
DoNOTmoveSeakeepermountedcomponentsfrom
theirlocationsorincorrectSeakeeperoperationwill
result.

