INSTALLATION
MANUAL
Product: Document #: Rev: Page:
SEAKEEPER 6 90402 1 7 of 7
Section 2: ELECTRICAL INSTALLATION
2.3 Electrical Equipment Ground Connections
1. SEAKEEPER TO VESSEL GROUND CONNECTION INSTRUCTIONS
a. Connect the Seakeeper foundation to vessel ground.
i. Install CABLE 6 (4AWG or 22.0mm
2
, Customer supplied) from the M6
brass ground stud on the Seakeeper rear brace to a suitable vessel ground.
FIGURE 8 – SEAKEEPER GROUND STUD ON REAR OF FOUNDATION
GROUND
STUD
