INSTALLATION
MANUAL
Product: Document #: Rev: Page:
SEAKEEPER 5 90402 1 1 of 4
Section 5: INSTALLATION CHECKLIST AND SUPPLIES


Please Complete Checklist and E-mail to customerservice@seakeeper.com
or telefax to +1.410.326.1199
5.0 Installation Checklist
Mechanical Checklist (reference Installation Manual Section 1)
 Seakeeper Foundation Installed in Hull
 Foundation bolts torqued to specification
Electrical Checklist (reference Seakeeper Drawing 90396 & Installation Manual Section
2)
Mount Components
 Display (near helm)
Connect Customer Supplied Cables
 Cable 6 (customer supplied) – Install lugs on both ends of customer supplied
10AWG ground cable
 – Connect one end of Cable 6 to nearest vessel
ground and other end to Seakeeper rear brace
Connect Seakeeper Supplied Cables
 Cable 1 (Seakeeper supplied) – Connect other end of Cable 1 to 12 VDC power
at customer supplied connection box or directly
to circuit breaker
 – Plug connector of Cable 1 into mating
connector on Seakeeper wire harness
 Cable 2 (Seakeeper supplied) – Connect Cable 2 from Drive Box to 110-230 VAC
single phase at customer supplied connection
box or directly to circuit breaker
 Cable 5 (Seakeeper supplied) – Connect Cable 5 from Drive Box to customer
supplied 110-230 VAC seawater pump
 Cable 3 (Seakeeper supplied) – Connect female end of CAN communications
Cable 3 to mating connector on Seakeeper wire
harness
