Section 5: INSTALLATION CHECKLIST AND SUPPLIES
– Route CAN communications Cable 3 from
Seakeeper to helm (male end goes to helm)
– Connect male end of CAN communications
Cable 3 at helm to CAN Tee Adapter
– Connect Display and Seakeeper supplied Cable
4 to CAN Tee Adapter with CAN Terminator
Cooling Checklist (reference Installation Manual Section 3)
Verify coolant level in heat exchanger coolant reservoir.
Connect sea water hoses / open sea cocks to heat exchanger and test sea water
pump.
Verify 4 GPM (15 LPM) minimum and 8 GPM (30 LPM) maximum sea water flow
through heat exchanger under all operating conditions of the boat.
Startup Checklist (reference Installation Manual Section 4 and Operation Manual
Section 2)
Remove lifting bolts and Install cover panels
Turn on 12 VDC circuit breaker
Turn on 110-230 VAC circuit breaker
Verify display works and no alarms are present
Follow instructions in Section 4.1 of Installation Manual to turn on the
SEAKEEPER
Verify sea water pump turns on when the SEAKEEPER is turned ON
Verify that no ALARMS are present
Follow instruction in Section 4.1 of Installation Manual to turn off the Seakeeper
AC & DC power and sea water pump may be turned off after the SEAKEEPER is
turned off by placing the SEAKEEPER in LOCK mode and Turning the
SEAKEEPER off
Seakeeper takes 4 or more hours to coast down to zero rpm from full speed
