4. ASSEMBLY
Original Language Version
© Jack Sealey Limited
1 DOOR WALL CABINET
STEP 1: Carefully separate the front and back panels, allowing the side panels to unfold completely.
STEP 2: attach the top panel using 8x M6x16mm screws. STEP 3: Turn the cabinet over. Attach the bottom panel using
11x M6x16mm screws.
STEP 4: Insert 4 shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports.
APMSHFP series | Issue 1 21/10/19
top panel
shelf support x4
shelf
