STEP 2: Attach the bottom panel using 11x M6x16mm screws.
STEP 3: Screw the 4 adjustable feet into
the cabinet bottom.
STEP 4: Attach the worktop to the cabinet using 4x M6x16mm screws.
STEP 5: Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports.
NOTE: The cabinet will only lock when the shelf is placed in the centre position.
APMSHFP series | Issue 1 21/10/19
2 DOOR BASE CABINET WITH WORK TOP
STEP 1: Carefully separate the front and back panels, allowing the side panels to unfold completely.
M6x16mm screws x4
shelf support x4
