STEP 2 TOP CABINET: Attach the top panel using
8x M6x16mm hex socket head screws.
STEP 4 TOP CABINET: Turn the cabinet over. Attach the bottom panel using 7x M6x16mm screws.
2 DOOR STACKING CABINET
STEP 1: Carefully separate the front and back panels, allowing the side panels to unfold completely.
STEP 3 BOTTOM CABINET: Place the top panel on the bottom cabinet.
Do not attach yet.
APMSHFP series | Issue 1 21/10/19
M6x16mm
screws x8
M6x16mm
screws x7
top panel
top
cabinet
top
cabinet
top
cabinet
bottom
cabinet
top panel
