7. ASSEMBLY
GSS150815 Issue: 1 - 24/08/12
7.1 ASSEMBLE THE REAR WALL PANELS
7.1.1 Youwillnditeasiertoassembletheshedusingtrestles,withtimberstuddingofequalorgreaterpanel
length. Trestles are available separately from your Sealey Dealer. Attach the studding to trestles with
 equaloverhangusingnyloncabletiesorsimilar“safe”method.
7.1.2 Place panel 14A and 11A on your work table and join them together with the 10mm long self tapping screws.
See the pre-punched holes and diagram below.
7.1.3Fittopandbottomchannels39Cand39Dtopanelsbyrstlyslidingandnallytappingintoplaceasindicated
 byarrowsinthediagramsNotethatthesmallerangeonthechannelsshouldalwaysbeadjacenttotheout
side face of the panel; this prevents rainwater entering the compartment of the shed. The outside face is the
top face in the diagram below.
