GSS1515.V2, GSS1515G.V2 Issue: 2(I) - 13/04/17
Original Language Version
© Jack Sealey Limited
Step 2:
A
ssemble the rear wall panels
You will find it easier to assemble your shed using sawhorses with timber studs attached (timber needs to be the same length as the
shed (1.5m)) or alternatively, a trestle table.
Place 2 x par
t 6A (sheet) on your worktable and join together with the self-tapping screws as per the diagram below.
Now fit part 20B (top channel) and part 20C (bottom channel) to the sheeting by tapping it in (diagram A) or sliding it in (diagram B).
Make sure the small lip of the channel is always facing out. This ensures rainwater cannot build up inside your shed.
A
950mm
20B
20C
TOP
6A
6A
RIDGES FACING UP
A
ROOF TOP EDGE
