Sealey GSS2323 - Page 16

GardenShed 2.3 x 2.3 x 2.4m
Step 6: Assemble the front door
Place part 5K (door sheet) on the worktable and fit 2 x parts M26, 24J, 24H (channels) to the door, fixing them with the provided 3.0
x 10mm rivets. Make sure the small lip on the channel is always facing out. This ensures rain water cannot build up inside your shed.
M26
M26
FIXW ITH3 .0*10MMR IVET
FIXW ITH3 .0*10MMR IVE
T
FIXW ITH3 .0*10MMR IVET
5K
24H
24J
ROOF TOP EDGE
RIDGES FACING UP
DO NOT FIX RIVETS HERE,
LEAVE FOR PAD BOLT.
FIX WITH 3.0MM RIVETS
FIX WITH 3.0MM RIVETS
FIX WITH 3.0MM RIVETS
DO NOT FIX RIVETS HERE,
LEAVE FOR PAD BOLT.
GSS2323/G | Issue:2(SP) 13/04/17
Original Language Version
© Jack Sealey Limited
Step 6: Assemble the front door
Place part 5K (door sheet) onto the worktable and t 2 x parts M26, 24J 24H (channels) to the door, xing them with the provided 3.0 x 10mm
rivets. Make sure the small lip on the channel is always facing outwards. This ensures rain water can not build up inside the shed.
