Sealey GSS2323 - Page 23

95
FIXI TW ITH1 6mmS ELF
TAPPINGS CREWS
FI
XI TW ITH1 6mmS ELF
TA
PPINGS CREWS
Attach part 95 (logo cap) and fix the roof panels using 16mm self-tapping screws as per diagram below.
FIX WITH 16MM
SELF-TAPPING SCREWS
FIX WITH 16MM
SELF-TAPPING SCREWS
GSS2323/G | Issue:2(SP) 13/04/17
Original Language Version
© Jack Sealey Limited
Attach part 95 (logo cap) and x the roof panels using 16mm self tapping screws as per diagram below.
