Sealey SDH102 - Specification; Operation; Operating Functions

9  Beforeattemptingtomovethedehumidier,emptythecontentsofthecollectiontank.Seesection4.1.4.
9 Use top carrying handle when moving unit.
9 Switch off and disconnect it from the mains before attempting any cleaning or other maintenance work.
9  Ensurethatthedehumidieriscorrectlyturnedoffwhennotinuse,andstoredinasafe,dryarea,outofreachofchildren.
NOTE: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
2. i INTRODUCTION
Compact, efficient, portable unit that extracts up to 10 litres of water per day. Removes excess moisture from air to prevent build-
up of mildew and mould. Features an adjustable timer ranging from 1-24 hours. Digital control panel for simple and smooth operation.
Refrigerant is environmentally friendly R290. Supplied with 3A 3-pin plug and drain hose for continuous operation.
3. i SPECIFICATION
Model: .......................................................................SDH102
Supply: ........................................................ 220V-240V/50Hz
Rated input/current:...............................................200W/1.1A
Condensate tank: ............................................................ 1.8lt
Dehumidifying capacity: ............................................ 10lt/day
Maximumairow: .......................................................80m
3
/hr
Nett weight: .................................................................... 10kg
Refrigerant/Charge: .................................................R290/40g
Working space: ..............................................................12m
2
Working Temperature: .................................... >=5
0
C, <=35
0
C
Body size (W, D, H): ................................ 296 x 217 x 416mm
Noise: ........................................................................40dB(A)
4. OPERATION
NOTE: Empty water tank before every use.
NOTE: During operation keep doors and windows closed.
NOTE:Placetheunitintheareatobedehumidiedensuringthatinlet and outlet grilles are unobstructed and that the unit is
positioned as stated in section 1.2. Close all doors and windows
4.1. OPERATING FUNCTIONS
4.1.1. DEHUMIDIFYING
4.1.1.1.  Turnmachineon(g1.5).ThehumiditysettingandfanspeedcanonlybeselectedwhilstinAutomode.Presshumiditysettingcontrol
 (g.1.4)(defaulthumiditysettingis50%).Humiditysettingsrangefrom30%to80%andcanbeselectedin5%incrementsbyrepeated
 pressingofthehumiditysettingcontrol.Selectrequiredfanspeed(g.1.2).
 Iftheroomhumidityis5%greaterthansetvaluetheunitwillstart.Iftheroomhumidityis5%lessthanthesetvaluetheunitwillstop.
 TheDisplay(g.1.7)willdisplaythecurrenthumiditylevelwhenrunning.Optionsselectedwillbehighlighted.IfModeissetto 
‘Continuous’ the fan defaults to high speed and cannot be changed.
4.1.2. INSIDE DRYING (prior to long term storage).
4.1.2.1.  Turnmachineon(g.1.5).PressInsidedryingcontrol(g.1.6)andthemachinewillstartinternaldehumidifyingprocess.Thedisplay
 panel(g.1.7)displays‘CL’andtheInsidedryingfunctionLEDwillash.Thisprocesswilltakeabout1hourandnootherfunctionis
available in this mode. It is possible to switch off the process or power off the unit at anytime during this period.
4.1.3. TIMING FUNCTIONS
4.1.3.1.  Timedoperation:Turnmachineon(g.1.5)SetHumidity(g.4),Fan(g.1.2)andMode(g.8).PressTimercontrol(g.1.1).PressTime
 controlagain(g.1.1)toselectbetween1and24hoursin1hourincrements.Aftersettimetheunitwillswitchoff.
4.1.3.2.  Timeddelayoperation:PressTimercontrol(g.1).PressTimecontrolagain(g.1.1)toselectbetween1and24hoursin1hour 
 increments.SelectMode(g.1.8)andFanspeed(g.1.2).SelectHumiditylevel(g.1.4).Aftersettimetheunitwillswitchon.
4.1.4. DRAINAGE
4.1.4.1. Water Tank:
 Whenthewatertankisfullthewarninglightonthecontrolpanel(g.1.3)willash,theunitwillstopworkingandabuzzerwill 
sound.
 Toremovethewatertankrstremovelowerfrontcoverbygentlypullingitfrombothsidesusinggriprecessestopullit.
Original Language Version
© Jack Sealey Limited
Item Description
1 Timer setting
2 Fan speed
3 Container full warning light
4 Humidity setting control
5 On/Off
6 Inside drying function
7 Display (humidity/time)
8 Mode key (Auto/Continuous)
fig.
1
SDH102 Issue 1 07/11/18
This product contains uorinated greenhouse gases. This product is
hermetically sealed. Refrigerant: R290 GWP: 3
Additional warning for appliances with R290 refrigerant gas
(refer to the ratings plate for the type of gas used)
CAUTION: RISK OF FIRE.
READ MANUAL CAREFULLY BEFORE USING THE APPLIANCE.
R290 refrigerant gas complies with European environmental
directives.
This appliance contains approximately 40g of R290 refrigerant gas.
Appliance shall be installed, operated and stored in a room with a
oor area larger than 2m².
