6.3. Assemble the 2 ladders on the base and attach the brace to the rst rung (g.12).
6.4. Replace the 4 pins
6.5. PLATFORM AND PROTECTION ASSEMBLY
6.5.1. Next attach the platform to the 6th rung. Sit on the platform and attach the 4 braces to the rungs on the inside of the uprights as shown
in the diagram in (g.13).
g.12
g.13
Original Language Version
© Jack Sealey Limited
SSCL1.V2, SSCL3, SSCL4 Issue:4 28/06/21
