7.1.1. Place the ‘2-rung’ ladder onto the ‘7-rung’ ladder and pre-assemble the diagonals as shown in the diagrams below (g.16).
7.1.2. Install the boosters on the base of the scaolding and assemble the lower diagonal attachments. Replace the 4 pins on the bottom of
the booster so that they can be locked into the base.
8. STABILIZER ASSEMBLY
8.1. Installation of stabilisers fastened to the uprights by means of two wing nut clamps (g.17):
g.16
g.17
Original Language Version
© Jack Sealey Limited
SSCL1.V2, SSCL3, SSCL4 Issue:4 28/06/21
