3. SPECIFICATION
Function Range Resolution Accuracy
DC Voltage
(V DC)
200mV 0.1mV
±(0.5% reading + 2 digits)2000mV 1mV
20V 0.01V
200V 0.1V
±(0.8% reading + 2 digits)
600V 1V
AC Voltage
(V AC)
200V 0.1V
±(1.2% reading + 10 digits
(50/60Hz)
600V 1V
DC Current
(A DC)
2000µA 1µA
±(1.0% reading + 2 digits)
20mA 10µA
200mA 100µA ±(1.2% reading + 2 digits)
10A 10mA ±(2.0% reading + 2 digits)
Resistance
200Ω 0.1Ω
±(0.8% reading + 2 digits)
2000Ω 1Ω
20kΩ 0.01kΩ
200kΩ 0.1kΩ
2000kΩ 1kΩ ±(1.0% reading + 2 digits)
Battery Test
9V 10mV
±(1.0% reading + 2 digits)
1.5V 10mV
NOTE!Accuracyspecicationsconsistoftwoelements:
1. (% reading) – This is the accuracy of the measurement circuit.
2. (+ digits) – This is the accuracy of the analog to digital converter.
NOTE! Accuracy is stated at 65°F to 83°F (18°C to 28°C) and less than 75% RH.
Diode Test: ...................................Test current of 1mA maximum, open circuit voltage 2.8V DC typical.
Continuity Check: ........................Audiblesignalwillsoundiftheresistanceislessthanapproximately30Ω.
Battery Test Current: ....................9V (6mA); 1.5V (100mA).
Input Impedance: .........................>1MΩ.
ACV Bandwidth: ..........................45Hz to 450Hz.
DCA Voltage Drop: ......................200mV.
Display: ........................................3 ½ digit, 2000 count LCD, 1.1” digits.
Overrange Indication: ..................“I” is displayed.
Polarity:........................................Automatic (no indication for positive polarity); Minus (-) sign for negative polarity.
Measurement Rate: ..................... 2 times per second, nominal.
Low Battery Indication: ................“BAT” is displayed if battery voltage drops below operating voltage.
Battery: ........................................One 9 volt (PP9) battery.
Fuses: .........................................mA, µA ranges; 0.2A / 250V fast blow.
A Range: ......................................10A/250V fast blow.
Operating Temperature: ...............32°F to 122°F (0°C to 50°C).
Storage Temperature: .................. -4°F to 140°F (-20°C to 60°C).
Relative Humidity:........................<70% operating, <80% storage.
Operating Altitude: ....................... 7000ft. (2000) meters maximum.
Weight: .......................................255g.
Size: ..........................................150mm x 70mm x 48mm.
Safety: For indoor use and in accordance with Overvoltage Category II, Pollution Degree 2. Category II includes local level,
appliance, portable equipment, etc., with transient overvoltages less than Overvoltage Category III.
