6) Tool Self-test: Checks if the LCD display, LED lamps and
keyboard are working normally.
7) Update Mode: Accesses the Update Mode.
Settings of the unit will remain until change to the existing
settings is made.
To enter the Setup menu
When the code reader is powered on, it displays a Main Screen.
(Figure 3.1)
Figure 3.1
From the Main Screen: Use the SCROLL button to select Setup,
and press the ENTER/Exit button. Follow the instructions to make
adjustments and settings as described in the above setup options.
(Figure 3.2)
Figure 3.2
System Setup 1/8
Language
Configure Monitors
Unit of Measure
Key Beep Set
Status Beep Set
To Next Page
