Sears Elite 665.12772K310 - Section 3 - Component Access; Insulation Blanket

COMPONENT ACCESS
Kenmore Elite 2013 Stainless Steel Tall Tub Dishwasher
n
3-1
Section 3:
Component Access
This secon provides service parts access, removal, and
installaon instrucons for the “Kenmore Elite Stainless Steel
Tall Tub Dishwasher.”
■ Insulaon Blanket
■ Removing Door Latch Strike
■ Door Spring Adjustment
■ Water Inlet & Drain Hose
■ Overll Assembly
■ Accessing Door Components
■ Removing User Interface
■ Removing Latch Assembly
■ Removing Electronic Control Board
■ Removing Dispenser Assembly
■ Spray Arms, Feed Tube, and Manifold
■ Tub Components–Stainless Steel Models
■ Removing the Upper Rack(s)
■ Removing Lower Spray Arm
■ Removing Filters
■ Removing TurboZone Manifold & Diverter Disk
■ Under the Tub Components
■ Heater
■ Removing Sump Assembly / Drain Pump
■ Removing Opcal Water Indicator
■ Removing Diverter Assembly
■ Removing Lower Spray Arm Sensor
■ Wash Motor Replacement
■ Notes
