Hanging the garage door opener will vary depending on your garage. Below are three example installations. Your
installation may be different. For ALL installations the garage door opener MUST be connected to structural supports. The
instructions illustrate one of the examples below.
HARDWARE
6、Install the light bulbs
CAUTION
To prevent possible OVERHEATING of the end panel or light socket:
· Use ONLY A19 incandescent or compact fluorescent light bulbs.
· DO NOT use incandescent bulbs larger than 100W.
· DO NOT use compact fluorescent light bulbs larger than 26W (100W)equivalent.
· DO NOT use halogen bulbs.
· DO NOT use short neck or s
p
ecialt
y
li
g
ht bulbs.
Fi
n
i
s
h
e
d
C
e
ili
ng
U
n
f
i
n
i
s
h
e
d
C
e
ili
ng
5.1On finished ceilings, use the lag
screws (H7) to attach a support
bracket (not provided) to the
structural supports before installing
the garage door opener
5.2 Make sure the garage door opener
is aligned with the header bracket.
Measure the distance from each
side of the garage door opener to
the support bracket.
5.3 Cut both pieces of the hanging
b
racket to re
q
uired len
g
ths.
H7
Not
p
rovide
d
5.4 Attach the end of each hanging
aligned bracket to the support bracket
with appropriate hardware (not
provided).
5.5 Attach the garage door opener to
the hanging brackets with the bolts
(H15), lock washers (H21) and nuts
(H20).
5.6 Remove the 2x4 and manually close
the door. If the door hits the rail,
raise the header bracket.
Not
p
rovide
d
H4
H4 Hex Bolt M8×20(2) H3 Hex
N
ut
H3
