8
2、Tighten the Chain
ASSEMBLY
H6
6
5
2.1 To increase the tension and tighten the chain,turn the
tension nut clockwise or adjustable wrench until the nut is
spaced properly from the rail end -plate.
2.2 Once the nut is spaced correctly,any additional tightening
will overtighten the chain and may cause damage to the
system.
2.2 To loose the tension,turn nut counterclockwise.
2.5cm
