INSTALLATION INSTRUCTIONS
Copy Part# 501002, Rev. C, 01/2014 Page 2 of 2
© 2008 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Fax: 604.270.7172 Web: www.seastarsolutions.com
CYLINDER SERVICE KITS:
HP6016, HP6018, HP6036 & HP6111
ITEM PART # QTY DESCRIPTION
1 N/A 2 Nut, 1/2" NF Nylok
®
SS
2 N/A 2 Washer, Flat 1/2" SS
3 N/A 2 Nut, 7/16" NF Nylok
®
SS
4 N/A 2 Washer, Flat, 7/16" SS
ITEM PART # QTY DESCRIPTION
5 N/A 2 Support Bracket, Front Mount
Cylinder
6 N/A 1 Support Rod
5
2
4
3
6
1
3
1
2
4
5
Figure C.
Use plastic spacer to
ensure there is no
metal to metal contact.
CAUTION
Use plastic spacer to
ensure there is no
metal to metal contact.
CAUTION
NOTICE
SeaStar Solutions no longer sells individual PID's. Any part number shown below is ONLY available in kit form.
