6
○ This product should be mounted on a horizontal, stable and rigid surface
for appropriate operation.
4) Plumbing
○ Connect the pumps exhaust port and rigid plastic pipe VP13 (ID 13mm x
OD 18mm) with an L-joint hose.
● Plumbing with smaller diameter pipe may cause excess pressure and
heat which will shorten the diaphragm and valve life.
● Be sure to secure connection with a hose clamp (Ref.: Fig 1).
● Do not twist the hose elbow.
○ The length of plumbing should be as short and straight as possible.
● If the plumbing length is over 16.4ft. ( 5m ), consult our distributor.
○ Make sure that nothing remains in the pipe during plumbing.
● If foreign material is left, it may cause excess pressure
and heat which will shorten the diaphragm and valve life.
5) Operation
○ The ambient temperature should not be over 104°F (40℃).
● Cooling fan is recommended to be installed when mounting in an area
of higher temperature.
○ To avoid the risk of fire or electric shock do not modify, heat or pull the
power cord.
○ Do not put a heavy load on the power cord. The power cord may be
damaged, if hazard is ignored.
○ Clean electric source plug connectors once a year and plug in securely.
●Dust on source plug connectors or improper plugging can cause fire or
electric shock.
○ Do not touch the electric source plug with wet hands.
○ Grasp plug to remove power cord from the outlet. Do not remove by
pulling on power cord.
○ Do not operate if the cord or plug is damaged or if this product is
malfunctioning, dropped, or damaged in anyway.
To Next Page
