Page 3
Setting up your Pipit 500
Powering the unit
Only use the adapter provided with your display to power it. Place
the unit in an easy-to-view location, near a power outlet.
Step 1: Insert the two AAA batteries supplied with the unit, taking care
to observe that they are fitted correctly, as indicated by the terminal
markings in the battery compartment (refer to page 15).
Step 2: Hold the display with
its rear facing towards you;
align the small end of the
power adapter cable vertically
with symbol ‘B’ facing towards
you and plug it into the socket
at the back of the display as
shown in the figure.
Step 3: Push the cable into the groove of
the cable grip to secure the connector.
Step 4: Plug the other end into a power
outlet and switch the power on. The start-
up screen should appear, as shown below.
