LENS
1.When the SETUP menu screen is displayed, select LENS
by
using the UP and Down buttons so that the arrow indi-
cates
LENS
* ELC/ALC: Select Fix iris and Auto Iris Lens.
EXPOSURE
1.Using this function, you can control screen brightness.
► BRIGHTNESS: You can control the brightness .
► SHUTTER: MANUAL/AUTO.
* MANUAL
NTSC: 1/30 ~ 1/60000,
PAL: 1/25 ~ 1/60000,
* FLICKER: Select this when you picture flicker.
* AUTO: Select this mode to control the shutter speed
automatically. Shutter speed is automatically controlled de-
pending on the brightness of the screen.
► SENS-UP: When it is night, the camera automatically
detects the light level and maintains a clear picture.
► AGC: You can adjust it . The higher the gain level, the
brighter the screen but the higher the noise.
BACKLIGHT
►HLC: To inhibit strong light and compensate bright-
ness of the area around it.
* LEVEL:0-20 * MODE :ALL DAY/NIGHT ONLY
► BACKLIGHT: This function allows you to get a clear
pictures of objects even the objects in strong backlight.
* H-POS/V-POS/H-SIZE/V-SIZE
► WDR: If there are bright area and dark area on the screen
at the same time, this function makes both areas to be in clear
image.
* LOW/MIDDLE/HIGH
WHITE BAL.
According to the color temperature of environment to
adjust the camera’s color.
* AUTO/AUTOext/PRESET/MANUAL
DNR
This function reduces the background noise in a low lumi-
nance
environment.
* LOW/MIDDLE/HIGH
► SHARPNESS（0~10）: Adjust the sharpness of the im-
age.
► GAMMA: Set the GAMMA value of camera.
► COLOR GAIN: 0~20.
► MIRROR: you can flip the image horizontally.
► FLIP: you can flip the image vertically.
► D-ZOOM: 1.0X~8.0X.
► ACE: Adaptive Color Enhancement.
If there are bright area and dark area on the screen at the
same time, this function makes both areas to be in clear im-
age.
* OFF/LOW/MIDDLE/HIGH
► SHADING: Lens shading compensation.
► PRIVACY: Hide an area you want to hide on the screen.
* ZONE NUM : 0~15
* ZONE DISP : ON/OFF
* H-POS/V-POS/H-SIZE/V-SIZE
* Y-LEVEL/CR-LEVEL/CB-LVEL
MOTION
► SENSITIVITY: When the number is high, the detection is
increased to recognize even small movement.
► WINDOW TONE: 0~6.
► DET H-POS:0~60.
► DET V-POS:0~40.
► DET H-SIZE:0~60.
► DET V-SIZE:0~40.
► MOTION OSD: ON/OFF.
► ALARM: ON/OFF.
SYSTEM
► COM.: Communication settings.
* CAM ID/BAUDRATE
► IMAGE RANGE: USER/FULL/COMP.
► OUTPUT MODE: 1080P/720P.
► COLOR SPACE: HD-CbCr/YUV/SD-CbCr.
► FRAME RATE: 25FPS/30FPS.
► CVBS: PAL/NTSC.
► LANGUAGE: ENG/CHN/CHN(S)/JPN/KOR.
► COLORBAR: OFF/ON.
► RESET
5
6
7
8
Function Menu
LENS
■ELC ■ALC
EXPOSURE
■BRIGHTNESS ■AGC ■SENS-UP ■AGC
BACKLIGHT
■HLC ■BLC ■WDR
WHITE BAL
■AUTO ■AUTOext ■PRESET ■MANUAL
DNR
■LOW ■MIDDLE ■HIGH
■SHARPNESS
■FLIP
■SHADING
■GAMMA
■D-ZOOM
■PRIVACY
■COLOR GAIN
■AEC
■MIRROR
■DEFOG
MOTION
■SENSITIVITY
■DET H-SIZE
■WINDOW
TONE
■DET V-SIZE
■DET H-POS
■MOTION OSD
■DET V-POS
■ALARM
SYSTEM
■COM.
■FRAME RATE
■IMAGE
RANGE
■CVBS
■OUTPUT
MODE
■LANGUAGE
■COLOR
SPACE
■COLORBAR
EXIT
OSD MENU
