Seeburg SP2 - SP2 Appendix and Specifications; Appendix Tables

4 Appendix
4.1 Tables
SIP-resistor- Frequency
array X-Over EQ1 EQ2 EQ3 EQ4
470 2400 330 1250 7000 19000
560 2100 305 1100 6400 17500
680 1600 280 1000 6000 16000
820 1400 290 920 5700 15500
1K 1200 240 880 5000 13500
1,2K 1000 205 800 4250 11500
1,5K 800 185 700 3800 10500
1,8K 750 162 610 3200 9200
2,2K 530 140 525 2850 8000
2,7K 430 120 450 2500 6750
3,3K 370 105 400 2200 5850
3,9K 310 90 350 1800 5000
4,7K 260 76 300 1600 4250
5,6K 220 65 250 1400 3700
6,8K 170 55 210 1200 3100
8,2K 150 45 175 1000 2700
10K 130 38 150 825 2250
12K 105 32 125 700 1800
15K 85 28 100 565 1500
18K 70 25 85 460 1250
20K 65 20 75 430 1150
Table 1 SIP resistor values and the corresponding 3 dB points of the frequency dividing network and EQ
center frequencies.
Resistor values given in ohms (Ω).
Frequencies given in hertz (Hz).
The resistor values are usually coded with three numbers on the SIP housing. The two most
significant digits represent the resistor value. The third number determines the magnitude by
defining the number of zeroes that must be attached to number one and two.
Examples: 222: 2200 Ω = 2,2 kΩ
153: 15000 Ω = 15 kΩ
