INSTALLATION INSTRUCTIONS

9) Proceed to place new decals on the sides of the cabinet. Locate a new monitor bezel, if needed, and

replace glass, if required (due scratches). Install Instruction Placard to the back of the Monitor Glass.

NOTE: As a precaution, disconnect the JAMMA Harness from the I/O Boards and turn power on. With a

Multi-Meter, measure the 5v and 3.3v. Adjust if necessary to 5.15v DCand 3.3vDC. Measure the +12 to

ensure the wires and voltages are in the correct position. Turn power off. Plug in the JAMMA Harness once

again to the I/O Boards. The Attract Mode should appear on the screen.

Adjust the SIZE, CONTRAST, BRIGHTNESS, and COLORS on the

Monitor for optimum appearance. Adjust VERTICAL/HORIZONTAL

Hold to get a stable picture, if required.

Enter DIAGNOSTICS and adjust the Volume Level, test all Buttons &

Joystick for proper operation & wiring. Adjust Pricing. Coin-Up and

test out a game to ensure proper play functions are as they should be.
