Counter Installation Manual [continued]
1. Connect the 5V Counter to the Wire Lead. Connect the
red and black wire of the 5V Counter to the like colors on
the wire lead.
2. Use the screws included to mount the 5V Counter to
the side wall of the 40” Monitor inclosure.
5V Counter
5V Power Lead
DBA Pulse Lead
Flat Head Hex Screws
