SEIF MINIFOCUS Series - Tools Required; Installation Guide; Installation on Metal Surface; Installation on Wood Surface

2
3
www.self-electronics.com www.self-electronics.com
1
Tools:
Pencil
Ruler
Ø7mm
(Ø1/4″)
Ø12mm(Ø1/2″)
Ø12mm(Ø1/2″) Ø12mm(Ø1/2″)
Driller
Drill bit
Hole opener
Hole opener
Installed on the metal:
H≥
2mm(1/16″)
2
4
3
5
LED Power Supply
Splitter
1
Ø12mm(Ø1/2″)
Installed on the wood:
H≥
3mm(1/8″)
2
4
3
