7
TECHNICAL GUIDE
• The explanation here is only for the particular points of Cal. 4F32A, 8F32A, 8F33A and 8F35A.
• For the repairing, checking and m easuring procedures, refer to the “ TECHNICAL GUIDE, GENERAL
INSTRUCTIONS” .
I. STRUCTURE OF THE CIRCUIT BLOCK
Cal. 4F32A, 8F32A, 8F33A, 8F35A
[ Cal. 4F32A ]
[ Cal. 8F32A, 8F33A and 8F35A ]
“ ø” terminal
(for resetting the date dial)
“ M ” terminal
(for month setting)
“ Y” terminal
(for year setting)
“ D” terminal
(for date setting)
AC terminal
Coil block output terminal
Input terminal (+)
C-MOS-IC
Input terminal (–)Crystal unit
“ ø” terminal
(for resetting
the date dial)
“ M ” terminal (for month setting)
“ D” terminal
(for date setting)
AC terminal
“ Y” terminal
(for year setting)
Coil block output terminal
Input terminal (+)
C-MOS-IC
Input terminal (–)Crystal unit
