Seiko 4R35B - Winding Mechanism Components

[ WINDING MECHANISM]
Barrel and train wheel
36
First reduction wheel
31 bridge screw
0511 010 0012 100
Refer to page 9 for oiling spot
Refer to page 12 for disassembling/reassembling
32-1
Cap jewelled spring
0015 703
Cap jewel
35
Pawl lever
0011 221
0831 ***
Sliding crown wheel spring
33 0363 ***
Refer to page 13 for disassembling
/reassembling
32
Barrel and train
wheel bridge
0114 ***
Refer to page 11 for oiling spot
Reduction wheel holder
37
0836 002
0436 164
38
Fourth wheel and pinion
0012 354
40 Third wheel and pinion
0231 070
41
Click
0381 004
42 Barrel complete
0201 ***
6/18
0241 010
32-2
PARTS LIST
Cal. 4R35B / 4R36A
34
Lower plate for barrel and
train
Lower plate for barrel and
train
39
*1
*1
Types of oil
AO-3 (Moebius A)
SEIKO Watch Oil S-6
SEIKO Watch Oil S-4
