Seiko 4R35B - Setting Mechanism Components

[SETTING MECHANISM]
43 Center wheel bridge screw
0012 354
44 Center wheel bridge
0122 302
45 Escape wheel and pinion
0251 300
46 Center wheel and pinion
0224 ***
47 Setting lever jumper screw
0012 168
48
Setting lever jumper
0388 ***
49 Yoke
0384 ***
50
Setting lever
0383 ***
51
Stop lever
0601 ***
Refer to page 12 for oiling spot
Clutch wheel
0282 ***
Winding pinion
0283 020
55
Day-Date corrector
setting transmission
Winding stem
0351 200
Refer to Page 12
Main plate
for disassembling.
52
0100/0104 ***
7/18
Cal.4R35B/4R36A
53
54
wheel A
PARTS LIST
56
0962 183
*1*1
*2
*2
*3
*3
*4
*4
whole tooth
*5
*5
Types of oil
AO-3 (Moebius A)
SEIKO Watch Oil S-6
SEIKO Watch Oil S-4
