Cal.5D88A TECHNICAL GUIDE
ILLUSTRATION AND SPECIAL INSTRUCTIONS ETC.
<62> Lubricate and set the fourth wheel.
Lubricate and set
the fourth wheel.
Refer to the Fig.24
Mount the train wheel setting
lever.
Refer to the Fig.25.
Mount the coil
block.
Mount the spacer
for generating stator
Refer to the Fig.23.
<61> Mount the train wheel setting lever.
Insert the tail portion of the train wheel setting lever with
the guideing slit at an angle into the gap of the circuit bridge, and securely set the guiding slit to the dowel pin of the setting
lever.
Mount the
generating coil
block.
Mount the
generating rotor.
Mount the
generating stator. Refer to the Fig.23.
<69> Mount the spacer for coil block rotor.
Mount the coil block.
When mounting the coil block, take care so as not to distort or deform the coil blocl core as it may cause
deterioration of the motor.
* Coil block resistance between 1.9KΩ and 2.15KΩ
(as reference value)
<70> Mount the generating coil block.
When mounting thegenerating coil block, take care so as not to distort or deform the coil block core as it may cause deterioration of the motor.
* Coil block resistance between 585Ω and 645Ω (as reference value)
<60>
Mount the
generating
rotor.
<72> Mount the spacer for generating stator. <71> Mount the generating stator.
When mounting the spacer for generating stator and generating
stator, take care so as not to distort or deform the
coil block
core as it may cause deterioration of the motor.
71
Mount the Spacer
for coil block rotor
