Cal.5D88A TECHNICAL GUIDE
ILLUSTRATION AND SPECIAL INSTRUCTIONS ETC.
<54>
Mount the
rechargeable
battery
connection (+).
57
Mount the power reserve stator.
53
Mount the power
reserve rotor.
Refer to the Fig.
28 for the align-
ment of the power
reserve rotor.
52
Mount the
Intermediate wheel
for power reserve.
Refer to the Figs.29 & 30 for the align-
ment of the inter-
mediate wheel for
Mount the power
reserve indicator
wheel. Refer to
the Figs.29 & 30 for the alignment of the
power reserve
indicator wheel.
51
Mount the
rechargeable
battery
connection (+).
54
57
53
52
51
power reserve.
30/51
51
(52) Intermediate
wheel for power
reserv
(53) Power reserv rotor
29
30
