Seiko 8T67A - Lubrication Guide; Component Lubrication Points

TECHNICAL GUIDE
8T67A
Type of oil Oil quantity mark
AO-3(Moebius A）
NORMAL QUANTITY
AO-2(Moebius F) SUFFICIENT QUANTITY
S-6
● Remarks for the lubrication
Hammer
Lower plate for chronograph bridge
Note:
*1: Lubricate on the pointed spot.
16
Switch spring
Oiling spot and spring setting position are below;
Chronograph coupling lever
Hammer operating lever B
Setting position
Switch spring
10/20
16
*Lubricate on the contact spot of the spring and the pin.
21
19
20
27
*1
*1
*2
*3
*2
*3
*1
*1
