2. Unit Configuration
The SLC4075 is supplied with a default database that includes the basic SLC4075 functionality. The unit requires
additional configuration if the following optional features are desired:
• Ethernet parameters
• User accounts and password
• Additional alarm notifications
a. For G304 Units, download the latest, free Crimson 3.0 software and manual from
i. http://www.redlion.net/Support/Downloads and find the Crimson3 software
b. For CR1000 units, download the latest, free Crimson 3.1 software and manual from
i. http://www.redlion.net/Support/Downloads and find the Crimson3.1 software
c. Connect 24V dc to the SLC4075, but do not turn on until instructed.
d. If changes to the database are desired, determine the method to update the database.
i. Method 1: The database download IP address is configured with a default address of 192.168.0.104
and the Link Options selection is TCP/IP. This method may be used to download updates to the
database without using the programming cable. The TCP/IP parameters may be changed so that
subsequent updates may use a corporate network address. Connect a laptop using an Ethernet switch
or make a direct connection. Verify that the wired adapter is enabled on the laptop.
ii. Method 2: Using Programming Cable Selectronix SLC4074-2 OR Red Lion Cable CBLPRO4K
1. Determine the COM port on the host PC that will connect to the TSGW.
2. Connect the Serial Programming Cable.
iii. Method 3: For SLC4075-7 only or any CR1000, update the database using an SD card.
iv. Method 4: For any CR1000, update the database using a USB cable after selecting USB in the link
options.
e. Power the unit
f. Open the applicable Crimson 3or Crimson 3.1
i. Open the delivered SLC4075_TSGW……….cd3 database or cd31 database
ii. For Method 1 update:
1. Select Link; Options; Set to the desired COM port on the host PC.
iii. For Method 2 updates using the default TCP/IP address:
1. Set the IP address on the PC running Crimson to 192.168.0.99 .
2. In the left window, Navigation Pane
a. Select the Communications Tab
b. select the Network item.
3. In the right window, select the Ethernet tab and configure the applicable parameters
4. From your network administrator, request a static IP and other required information OR set
the initial Port Mode to “Configured via DHCP or APIPA”. The unit will request an IP on
power up. Note that after this IP is assigned, it is recommended that you request that the
network administrator reserve that IP address for this specific unit. The Port Mode can then
be changed to Manual Configuration with the assigned network information.
5. If Ethernet is to be used for subsequent unit updates:
a. Select Communications Tab; Network item; Download tab and change IP
Download to Enabled and set the Unit Addressing to Manual and enter the
desired Remote Address. Note that this IP address may be different from the IP
address entered in the Ethernet tab. Having separate IP addresses for unit
addressing and for database downloads facilitates multiple unit upgrades without
having to change the download IP address for each unit.
b. Select Link;Options, and set the desired link to TCP/IP.
iv. For Method 3, go to section “Configuration using SD Card“, on the next page.
v. For Method 4, Select USB in the Link Options.
vi. After all configuration and database options have been programmed
1. Select top menu, Link;Update
