8mm
15mm
F CONNECTOR
3mm
CONNECTOR COVER
TO ANTENNA
LNB
REC
FROM RECEIVER
ROTOR
ANTENNA
Cable 2
Cable 1
Scart
Cable 2
TV
RECEIVER
RECEIVER
Cable 1
LNB
REC
- On a coaxial cabel approximately 1,5 m long, set up 2 F-connectors.
- Connect the antenna to the rotor's LNB plug.
- Fit an F-connector on each end of the cable going to the reciver and
connect the rotor's REC plug to the plug of the receiver.
Resistence= 18 /Km (max)
Resistence= 22 /Km (max)
Ø=1,13mm
Resistence= 10 /Km (max)
Resistence= 18 /Km (max)
Ø=1,02mm
LENGTH: from 30 m to 60 m
LENGTH: up to 30 m
Characteristics of the coaxial cable
5
A8 (2)
+ A7 (4)
LATITUDE
45° ÷ 70°
LATITUDE
10° ÷ 45°
6
4
ENGLISH
