EN - 2
INSTALLATION
Plug the AC/DC adaptor to an AC household outlet, and then plug
the DC jack to the back of the unit. Your clock is ready to work for you.
BACKUP BATTERY INSTALLATION
Your clock requires one CR2032 lithium battery (not included) to
provide backup power to the clock in the event of a temporary power
interruption.
1. Place your unit face down on a fl at and soft
surface.
2. Use screw driver to open the backup battery
compartment door located on the back of the unit.
3. Slide and remove the battery cover at the bottom
of your unit.
4. Insert one new CR2032 lithium battery into the
battery compartment with the “+” side facing up as
indicated.
5. Close the battery compartment door and tighten
the battery door screw.
1
2
If AC power is interrupted, the LED display will go off and the alarm
will not function. The backup battery will keep the time and all
settings of your unit. Make sure a fresh CR2032 lithium battery is
used. A fresh CR2032 battery could backup your clock continuously
for around 3 days.
SETTING TIME AND THE SNOOZE DURATION
1. Press SET once, the hour digits fl ash. Press or to set
the current hour (hold to advance rapidly).
2. Press SET again, the minute digits fl ash. Press
or to set
minutes. (hold to advance rapidly).
3. Press SET again, the display shows “05” and fl ashes.
Press
or to select your snooze time from 5 to 60 minutes.
4. Press SET again or if no key is pressed in approx. 10 seconds
to exit the setting mode.
