Sengoku Mega-23K - Unpacking and Assembly

㈰ Heater
㈪ Drip Tray
㈫

Burner
㈬ Top Plate
㈭ Front Grill
㈮ Rear Grill
㈯ Top Grill
㉀ Bail Handle
㉂ Batteries
㉃ Siphon Pump
㈷ Wall guards
㈹
㈺
II. UNPACKING AND ASSEMBLY
Assembly
Unpacking
Remove the heater and all packing
materials from the box.(see fig.1)
Take time to locate each of these
items:
Reach inside the body of the heater,
remove all packing materials and
take out the burner.
After locating each of these items,
remove the styrofoam and all other
packing materials in the box.
Save the box for summer storage.
1. Drip Tray
Place the heater on the drip tray
and lock in position by turning
clockwise.(see fig.2)
2. Side Grills
Locate front and rear grills.
Take the rear grill and insert the
mounting wire into the upper slot,
both top and bottom.
Repeat this procedure with the front
grill on the opposite side of the
heater. (fig.3)
Side Grills MUST BE INSTALLED.
Drip Tray
(
fig.1
)
(
fig.2
)
(
fig.3
)
-
3
-
Burner
Heater 's Body
Drip Tray
Burner/Burn Chamber
Top Plate
Front Grill
Rear Grill
Top Grill
Bail Handle
Wall guards
Batteries
Siphon Pump
Owner's Manual
Safety Tips
