Sennheiser A 3700 - Operating Elements

2
Operating elements
쐃 LED operation indicator
쐇 BNC socket, RF output (RF out)
쐋 Amplification selector
쐏 Mounting thread (3/8‘‘ or 5/8‘‘)
LED operation indication
쐇
쐏
쐃
쐋
쐃
red
LED color Selector position Amplification
green
blue
white
bypass/-3 dB
+5 dB
+10 dB
+15 dB
