Specifications
242 | ADN Digital Conference System
ADN-W AM antenna module
ADN-W C1 and ADN-W D1 wireless conference units
Microphone
See “ADN-W MIC 15 gooseneck microphone for wireless conference units” on
page 243.
RF frequency ranges 2.4 GHz; 5.1 to 5.9 GHz (see page 251)
RF output power 25 to 100 mW (depending on the selected
country/region, see page 251)
Power supply 12 to 15 V
alternatively via ADN PORT bus 52.8 V
Power consu
m
ption 6 W
Antennas 3 rod antennas with R-SMA connection
Transmission range typ. 30 m
Mounting thread 5/8" and 3/8" thread insert
Temperature range operation: +5°C to +45°C
storage: -25°C to +70°C
Relative humidity operation: 20 to 95%
storage: 10 to 90%
Dimensions (W x H x D) approx. 226 x 181 x 58 mm
Weight approx. 1660 g
RF frequency ranges 2.4 GHz; 5.1 to 5.9 GHz (see page 251)
RF output power max. 100 mW (depending on the selected
country/region, see page 251)
Audio quality 16 bit / 32 kHz
Operating time approx. 20 hours (ADN-W BA battery pack)
Voltage of optional external
power supply
12 V via ADN-W BA battery pack
Charging time of battery pack typ. 4 hours
Headphone socket 3.5 mm stereo jack socket
Output level at
headphone socket
50 mW/16
THD (at 1 kHz) 0.03% at 50 mW/16
Frequency response 100 Hz to 14.5 kHz
Signal-to-noise ratio > 70 dB(A)
Temperature range operation: +5°C to +45°C
storage: -25°C to +70°C
Relative humidity operation: 20 to 80%
storage: 10 to 90%
Dimensions without gooseneck
(W x H x D)
approx. 185 x 67 x 180 mm
Weight (incl. battery pack) approx. 940 g
