3
Pos. Resulting sound Commentary
B.1 • many trebles
• aggressive sound
microphone directed towards the dome
of the loudspeaker
B.2 • less trebles,
more lower mids,
smoother sound
• balanced, natural
sound
good starting position:
• microphone directed towards the
middle between dome and edge of
the loudspeaker
• If necessary, turn the microphone by
approx. 30° towards the edge.
B.3 less trebles,
more lower mids,
smoother sound
microphone directed towards the edge
of the loudspeaker
Cleaning and maintaining the e 609 silver
Caution Liquids can damage the electronics of the product!
Liquids entering the housing of the product can cause a
short-circuit and damage the electronics.
X
Keep all liquids away from the product.
X
Do not use any solvents or cleansing agents.
X
Only use a soft, slightly damp cloth to clean the product.
Specifications
Transducer principle dynamic
Frequency response 40 … 15.000 Hz
Pick-up pattern super-cardioid
Sensitivity
(free field, no load at 1 kHz) 1,5 mV/Pa
Nominal impedance (at 1 kHz) 350 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions h: 55 mm, l: 134 mm, w: 135mm
Weight 140 g
The polar diagram and the frequency response curve C can be found on
the cover pages.
