Sennheiser K 6 - Page 2

Battery LED
On/Off
Bass roll-off filter
Frequency response
Cleaning
10
dBV
0
-10
-20
-30
-40
100 200 500 1.000 2.000 5.000 10.000 20.000 Hz5020
Specifications
+
normal
bass roll-off
Electrical impedance
Min. terminating impedance
Sensitivity (at 1 kHz)
Current consumption
Max. output voltage (no load)
Phantom power
Power supply battery (K 6 only)
Battery operating time (K 6 only)
Connector
Dimensions
Weight
approx. 200 Ω (bal.), approx. 100 Ω (unbal.)
1 kΩ
0 dB
2.2 mA
2 V (corresponds to 6 dBV)
12 - 48 V ⎓, 2 mA
1.5 V
max. 150 h
XLR-3
K 6: ⌀ 22 x 94 mm
K 6-P: ⌀ 22 x 52 mm
K 6: 45 g (without battery)
K 6-P: 30 g
K 6
Low battery
Battery
