ENGLISH
Pag. 12
Displayed
name
Meaning Description
THr1 Threshold 1 Displays and allows editing of the rst alarm threshold
THr2 Threshold 2 Displays and allows editing of the second alarm threshold
THr3 Threshold 3 Displays and allows editing of the third alarm threshold
HYSt Hysteresis Displays and allows editing of hysteresis of the alarm thre-
sholds
rES Reset Reset of the Fault status
PAIr Pairing It allows the pairing between the sensing element and the
detector
VEr Version Detector rmware version
Adr Address To display and set the detectors’ address on the RS485 bus
bAUd Baudrate Displays and allows editing of the baud rate of the serial port.
List of available values: 9600, 115200
Depending on the detectors’ series, dierent menu entries are available. The following table
reports the available items per each type of detector
Table 3) Menu component available per each detector of SMART series
SUB-MENO SMART series
3G 3R 3H Serie LITE P S
Password Always requested at the start, the password is 1234 for all the gas detec-
tors.
Zero Available for all detectors, if at least one sensor is connected
Span Available for all detectors, if at least one sensor is connected
4-20 mA x
Thr1 x 
Thr2 x  x  x  x  x  x 
Thr3 x  x  x  x  x  x 
Hysteresis x  x  x  x  x  x 
Reset x x x x x x
Pairing x x
Version x x x x x x
Address x[2] x x x x x
Baudrate Visualised
only[2]
x x x Visualised
only
x
[1] To modify the alarm thresholds and the hysteresis value, the menu password is 5345.
[2] For old SMART 3G versions, the address and the baudrate options are not present.
