ST-2200 PROCESSOR COMMANDS - QUICK REFERENCE
Function
Number
Description
Range
Low
Range
High Default
00
General
01 Product code 1 10 1
02 Password ****** ****** ******
03 Sample Rate 1 1S 10ms
04 Damping 0 120 0
05 Decimal selection 0 2 1
06 Pre-zero
07 Standardization 25
08 Sampling Mode 0 4 1
09 Batch Average mode No Yes No
10 Void Time 1
11 ATRO No
19 New Password ******
20 Limits
21 Low moisture limit -5.0 99.9 -5.0
22 High moisture limit 0 9999 100
23 4 mA out moisture 0 100 0
24 20 mA out moisture 0 100 100
25 Auto product loss 0 9999 0
26 Auto product return 0 9999 9999
27 Timed sampling fill time 0 99 1
28 Timed sampling purge time 0 10 1
29 Reference 0 100 15
30 Dielectric
31 Dielectric mode 1 3 1
32 Dielectric span -99.999 99.999 1
33 Dielectric zero -999.99 999.99 0
40 Temperature
41 Temperature compensation No Yes No
42 Temperature coefficient...Kt1 -99.999 99.999 0
43 Temperature coefficient...Kt2 -99.999 99.999 0
44 Temperature nominal -999.99 999.99 0
50 Weight
51 Weight compensation No Yes No
52 Weight coefficient...Kw N/A N/A 0
53 Weight nominal -999.99 999.99 0
54 Weight...keyboard entry 0 999.9 0
60 Distance
61 Distance compensation Off On Off
62 Distance coefficient...Kd -99.999 99.999 0
63 Distance nominal N/A N/A 0
