SENSORWORX SWX-801 Series User Manual

CONFIGURATION SETTINGS CONT.
LEFT FUNCTION #2 TURN OFF SCHEME
LEFT BUTTON
SETTING # VALUES NOTES
2
Unit fades to low trim and signals
relay to open
Default for all models
3
Unit fades dimming output down to 0
volts (i.e. below a connected driver’s
electronic off level). Relay remains
closed
4
Unit fades dimming output down to
low trim level. Relay remains closed
RIGHT FUNCTION #2 TURN ON DIMMING LEVEL
RIGHT BUTTON
SETTING # VALUES NOTES
2 Fade on to 100% of High Trim
3 Fade on to 50% of High Trim
4 Fade on to last user level Default
5 Fade on to current (custom) level Saves unit’s current dim level
LEFT FUNCTION #3 LOW TRIM
LEFT BUTTON
SETTING # VALUES NOTES
2 Saves current level as low trim
3 0%
Exact output voltage level depends on
Dimming Curve selected (e.g. Linear,
Log). Light output at each level depends
on driver/ballast and luminaire.
4 10% (Default)
5 20%
6 30%
7 40%
8 50%
RIGHT FUNCTION #3 HIGH TRIM
RIGHT BUTTON
SETTING # VALUES NOTES
2 Saves current level as high trim
3 100% (default)
Exact output voltage level depends on
Dimming Curve selected (e.g. Linear,
Log). Light output at each level depends
on driver/ballast and luminaire.
4 90%
5 80%
6 70%
7 60%
8 50%
LEFT FUNCTION #4 FADE OFF TIME
LEFT BUTTON
SETTING # VALUES NOTES
2 0.75 Sec
3 1.5 Sec Default for all models
4 3 Sec
5 5 Sec
6 15 Sec
RIGHT FUNCTION #4 FADE ON TIME
RIGHT BUTTON
SETTING # VALUES NOTES
2 0.75 Sec
3 1.5 Sec Default for all models
4 3 Sec
5 5 Sec
6 15 Sec
LEFT FUNCTION #5 MANUAL DIMMING RESPONSE CURVE
RIGHT BUTTON
SETTING # VALUES NOTES
2 Linear Default for all models
3 Log
4 Square Log
CENTER FUNCTION #7 LED FUNCTION
CENTER BUTTON
Single button switch (SWX-801) has an LED that is white when lights are on and is a blue locator LED when lights
are off. Dimming switch (SWX-803) has ve white LEDs that indicate the current dim level. Locator LED can also
be programmed to be be white and/or brighter. Locator LED can also be disabled
SETTING # DESCRIPTION NOTES
2 White LED when lights on, blue locator LED when off, normal brightness Default
3 Blue LED when lights on, white locator LED when off, normal brightness
4 All LED functionality disabled.
5 White LED when lights on, blue locator LED when off, increased brightness
6 Blue LED when lights on, white locator LED when off, increased brightness
CENTER FUNCTION #8
RESTORE FACTORY DEFAULTS
CENTER BUTTON
SETTING # DESCRIPTION
3 Restore Factory Defaults
