SCHEMATIC DIAGRAM
For product demonstration please view on You Tube or via www.sentinelprotects.com/uk/eliminator
Directional T piece
Flow arrow
Dual seals
Bleed valve
Isolation valve
Isolation valve
Collar
Collection bin
Cyclone
cartridge
Magnet tray
Anti tamper drain valve
Washer
Fig. 1
