Accessories
The following parts are optional for specific models.
If your dryer has any of the following parts, wear gloves and
them following the instructions below .
install
Hose holder (optional)
Condensing drain
hose (optional)
Use pliers to
remove the drain
hose from the
hose connector.
Insert the
external
drainage
hose.
Product Overview
Max. 120cm
200
cm
Put the hose holder on the
basin or any other sink.washing
Installation
Installation Position
Transport
Move cautiously. Do not grasp any salient parts of the machine. The
machine be used as the handle for delivery. If the dryer door cannot
can’t be transported horizontally, it can be slanted up to 30 degrees.
Level Adjusting
Once in its permanent operating position,
check that the dryer is absolutely level with
of a spirit level. If it is not, adjust the
feet with a tool.
the aid
Power Supply Connection
1.It is recommended that, for your convenience, the machine is
your washing machine.
2.The tumble dryer must be installed in a clean dry place, where
Air must be able to circulate freely all round
front air inlet or the air intake
3.To keep vibration and noise to a minimum when the dryer is in use,
placed on a firm and level surface.
4.The feet must never be removed. Do not restrict the floor
deep pile carpets, strips of wood or similar.
would interfere with the
operation of the product.
positioned close to
dirt does not build up.
the product. Do not obstruct the
grilles at the back of the machine.
it should be
clearance through
This might cause heat built-up which
1.Make sure that the voltage of the power supply is the same as the
2.Do not connect the dryer with the power connection board, the
electric specification of the dryer.
Mains power
cable
Filter door
Container
Door
Control panel
Air inlet
Filter base
Maintenance cover
Drum
Top board
Note: Diagram is for reference. Your model may differ slightly. The product you purchased will prevail.
universal plug or socket. do not use multi-plug adapters and
extension cables.
10 11
