2 TetraGraph Model SEN 2001, SEN 008, Issue 14.0, 2023-11-07 INSTRUCTIONS FOR USE
4
3
65
1
2
1. Baery symbol with charge status indicaon light.
2. ON switch
3. Cable connector for the TetraCord paent cable.
4. Aachment for the TetraGraph pole clamp.
5. RS 232 port interface for mul-parameter paent monitors.
6. USB-port for the USB cable (power supply and data upload).
Device layout
