Page 7
Dimensions
91.7(L) x 57(W) x 61.2(H) mm
Wireless
Standards
IEEE 802.11 b/g/n
Antenna Internal x 2
LEDs 1 * Power
1 * Wireless / WPS
1 * Ethernet
1 * PoE
PoE IEEE802.3 af Class 3
Maximum outpout power : 10 Watts
DC 48V, 208mA(maximum)
Over current protection
Data pin : 1, 2, 3, 6
Power pin : 4, 5, 7, 8
Ethernet
Interface
1 * RJ45 LAN Port
Auto-negotiation, Auto MDI/MDIX
Ethernet
Standards
Ethernet specification IEEE802.3,
IEEE802.3u, IEEE802.3x
AC Input 100 - 240VAC, 50-60 Hz, 0.8A(maximum)
Operating
Temperature
0
°
C to 45
°
C
Storage
Temperature
-25° C to 70° C
Operating 10-90%RH (max)
56.9
