Serpent S411 - Page 66

Serpent 411 SERPENT
Part no Description
802361 Bodymount adjustable rear (2)
FRONT SECTION
1652
Steel balls 5.8mm long (4)
401375
Suspension bracket alu 0
401024 Ball 5mm (10) 401378
Suspension bracket alu 3
401356
Camber link M3x26mm
401415
Antirollbar 1.2mm
401357
Foam bumper
401416
Antirollbar 1.6mm
401358
Stabi collar (2)
401417
Antirollbar 1.8mm
401359
Pully solid axle 38T
401418
Suspension bracket alu 1.5
401361
Bumper upper/ lower
401419
Suspension bracket alu 2.5
401362
C-hub 4 L+R
401420
Suspension bracket alu 3.5
401363
Steeringblock L+R
401422
Steeringblock alu L+R
401365
Bearingblock alu
401423
C-hub 2 alu L+R
401373
CVD axle set steel (2)
401424
C-hub 4 alu L+R
401376
Suspension bracket alu 1
401425
C-hub 6 alu L+R
401377
Suspension bracket alu 2
401426
Spacer suspension 0.5mm (2)
401379
Antirollbar 1.4mm
401430
Camberlink alu (2)
401380
Solid axle/spool
401428
Driveshaft adaptor delrin (2)
401381
CVD insert (2)
401433
Weight set brass 5gr - 12gr - 20gr (2+1+1)
401382
Shocktower mount alu L+R
401434
Bushing smaller bearing (4)
401384
Shocktower carbon front 401445 Driveshaft double cardan joint DCJ (2)
401386
Pivot pin front inner (2) 401446 Driveshaft DCJ (2)
401387
Wheelhexagon 1mm offset (2) 401447 Wheelaxle DCJ (2)
401388
Bushing alu 3x5x1 (10) 401448 Coupler DCJ (2)
401389
Bushing alu 3x5x2 (10) 401449 Insert DCJ (4)
401390
Bushing alu 3x5x4 (2) 401450 Pin revision set DCJ (4)
401391
Antirollbar ball (2) 401452 Wishbone Fr Lw hard (2)
401392
Bearing excenter (4) 401455 C-hub 4 L+R hard
401394
CVD driveshaft (2) 401459 Wishbone Fr Lw medium (2)
401397
Wishbone front lower (2) 401462 C-hub 4 L+R medium
401402
Antirollbar mount alu 401467 Pivot pin front inner TiNI (2)
401404
Suspension spacer 1mm (2)
401405
Pivot pin front-outer (2)
401406
CVD wheelaxle (2)
401410
Bushing steeringblock (4)
401411
Antirollbar bushing (16)
411063 Pivot ball threaded upper arm (2)
411187
Pivotball with shaft (2)
411206
Balljoint 4.5 (4)
411207
Balljoint 4.5 short (2)
411253
Pivotball uni 4.5mm (4)
802211
Bodymount adjustable front (3)
MIDDLE SECTION
1606
Antenna rod black (2)
401427
Pully 19T alu
401354 Chassis carbon 2.5mm
401431
Topdeck carbon 2.5mm
401360
Pully middle 19T + spacer (3)
401432
Chassis carbon 2mm
401366
Middle shaft alu
401433
Weight set brass 5gr - 12gr - 20gr (2+1+1)
401367
Motormount bracket alu 401451 Motormount set V2
401368
Motormount alu 401463 Belt tensioner set
401374
Topdeck carbon 2mm 401464 Battery mount carbon F/R
401398
Bracket middleshaft alu
401399
Bearingmount middleshaft alu
401413
Battery mount (4)
REAR SECTION
1652
Steel balls 5.8mm long (4) 401352 Belt Kevlar 30S3M186
Optionals
Optionals
Optionals
29/08/2011 2 OF6 parts list S411-v3
